Allied A96US2V - Blower Performance Data (Models 045;070); A96 US2 V045 B12 S Blower Performance

507404-02Page 52 of 80 Issue 1448
HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 900 1115
+18% 855 1060
+12% 810 1010
+6% 770 955
Fauctory Default 725 900
-6% 680 845
-12% 640 795
-18% 595 740
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 605 745 855 965 880 1045 1210 1375
Factory 550 675 775 875 800 950 1100 1250
- 495 610 700 790 720 855 990 1125
A96US2V045B12S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
HEATING
1
Heating Speed Dip
Switch Setting First Stage heating Speed - cfm Second Stage Heating Speed-cfm
+24% 1085 1210
+18% 1035 1150
+12% 980 1090
+6% 928 1035
Fauctory Default 875 975
-6% 825 915
-12% 770 860
-18% 720 800
COOLING
1
Cooling Speed DIP
Switch Settings
First Stage Cooling Speed -cfm Second Stage Cooling Speed-cfm
Low Medium-Low Medium-High
2
High Low Medium-Low Medium-High
2
High
+ 605 740 855 955 880 1045 1210 1375
Factory 550 675 775 875 800 950 1100 1250
- 495 610 700 790 720 855 990 1125
A96US2V070B12S BLOWER PERFORMANCE (less lter)
0 through 0.8 in. w.c. (Heating) and 0 through 1.0 in. w.c. (Cooling) External Static Pressure Range
1
Cooling and Heating speed are based on a combination of DIP switch setting on the furnace control. Refer to installation instructon for specic DIP
Switch settings
2
Factory default setting
NOTES: The effect of static pressure is included in air volumes shown.
First stage Cool (two stage air conditioning units only) is approximately 70% of the same second stage COOL speed position
Continous Fan Only speed approximately 50% of the selected second stage cooling speed - minimum 500cfm.
