(menu "Main page" > "Overview") is displayed and can be configured further.
Add sensor/actor via multiplex hub
If you would like to add a sensor/actor via an I2C multiplex hub, such as ALL4404 or ALL4504, the
same procedure applies as described in chapter 8.2.1 on page 68. In the following example, the
multiplex hub ALL4504 is used with 8 I2C sensor/actor ports. The connection to the host is done
here via the I2C port "1" (purchased) of the ALL3500.
Click on "Select All" to select all I2C ports.1.
