Series AE1L, AE.E, AE.N, AE.H, AE.V, AED1E, AED2N
Design ID, ZD
7.1.2.6 Packing ring dimensions (for Chapter 7.1.2.3), lubricant quantities for joints (for Chapter 7.1.2.1), bearings (for Chap-
ter 7.1.2.2) and flushing liquid flows (for Chapter 6.1.2)
Pump size
AE1L
51
101
201 381
551
751
1001
1451
2701 5001 – –
AE1E 50 100 200
380
550
750
1000
1450 2700 5000 9500
AED1E 75 150 300 560 1200 2300 4250 7800 15500
AE2E 50 100 200 380 750 1450 2700 – –
AE1N 25 50 100 200 380 750 1450 2700 5000
AE2N
AE4N
25
25
50
50
100
100
200
200
380
380
750
750
1450
1450
2700
–
5000
–
AED2N 38 75 150 300 560 1200 2300 4250 7800
AE1+1H – – – – – – – – 2700
AE2H – – – 100 200 380 750 1450 –
AE2+2H – – – 100 200 380 750 1450 2700
Pump series
AE4H 12 25 50 100 200 380 750 1450 –
AE4+4V – – 25 50 100 200 380 750 1450
AE2+2V – – – – 100 200 380 750 1450
Number of packing rings
for design P01/P11 ①
6 6 6 6 6 6 6 6 6
Dimensions of the packing
rings with cut rings
Ø
37 /
25 x 6
Ø 42 /
30 x 6
Ø 51 /
35 x 8
Ø 59 /
43 x 8
Ø 73 /
53 x 10
Ø 80 /
60 x 10
Ø 99 /
75 x 12
Ø 118 /
90 x 14
Ø 142 /
110 x 16
Dimensions of the packing
rings as blank L
M
x S
104,2
x 6
121
x 6
144,5
x 8
171,4
x 8
211,8
x 10
235,3
x 10
292,5
x 12
349,6
x 14
423,6
x 16
Oil quantity in cm
3
per joint
10 18 37 52 87 169 290 565 885
Grease quantity in grams
per bearing
70 135 225 280 530 680 1270 2050 4070
Flushing liquid flow
water l/min
0,05 0,07 0,09 0,11 0,11 0,15 0,21 0,27 0,78
c With shaft seal designs P02/P12, P03/P13 and P04/P14, the quantity is reduced by 1 unit.
