Appendix
9.2.9 Technical data for specific pump groups
Below pumps are classified in pump groups based on series and size. Specific technical data for the packing gland, lubrication
quantities and volumetric flow rates app ly to each pump group.
Series Size
AE-F
AEB-F
–
103 203 403 553
703
1003
1603
3003 5503
––
AE-L
AEB-L
–
51
101
201 381 551
751
1001
1451
2701 5001
––
AE-E 5000 9500
AEB-E
–
50 100 200 380
550
750
1000
1450 2700
––
AED-E
–
75
150 300 560 1200 2300 4250 7800 15500
AE-N
–
2700 5000
AEB-N 1
2
5
12
25 50 100 200 380 750 1450
––
AED-N 4250 7800
AEDB-N
–
38
75
150 300 560 1200 2300
––
AE-H 12 25 50 100 200 380 750 1450 2700
AE-V
–
––
25 50 100 200 380 750 1450
Pump group 1 2 3 4
5
6
7
8910
Tab. 33 Pump groups
Technical data for packing gland
Values by pump groupParameter
1234
5
6
7
8910
Number of packing
rings for version
P01/P11
5
666666666
Number of packing
rings for versions
P02/P12, P03/P13,
and P04/P14
4
555555555
Dimensions of the
packing rings for ring
blanks
Ø37/
25 x 6
Ø37/
25 x 6
Ø42/
30 x 6
Ø51/
35 x 8
Ø59/
43 x 8
Ø73/
53 x 10
Ø80/
60 x 10
Ø99/
75 x 12
Ø118/
90 x 14
Ø142/
110 x
16
Dimensions of the
packing rings as
blank L
M
xS
104.2
x6
104.2
x6
121
x6
144.5
x8
171.4
x8
211.8
x10
235.3
x10
292.5
x12
349.6
x14
423.6
x16
Tab. 34 Technical data for packing gland according by pump group
