PAGE 21 ALMAC s.r.l.
• Do not CHANGE DIRECTION on kerbs, rocks or appreciable differences in level
(> 10 cm) when driving the machine. In this case, always proceed
perpendicularly to the obstacles.
• If you must drive up a slope, do not change direction when the ground
changes from flat to sloping. If this is absolutely necessary, perform the
manoeuvre gradually.
• Do not drive along the edge of slopes or over uneven ground with one track
horizontal and the other slanting or partially raised (>10°) as this will damage
the tracks. ALWAYS PROCEED WITH THE TRACK SHOES RESTING ON THE SAME
HORIZONTAL PLANE.
• Driving over an obstacle creates a gap between the bearing rollers and track,
which could consequently slip out of its housing.
• If you change direction in a situation where the track could move sideways
owing to an obstruction, the track could slip out of its housing.
