PAGE 48 ALMAC s.r.l.
1. Maximum system pressure valve : set to 220 bar;
2. Maximum system pressure valve : set to 220 bar.
Warning: modifications to the positions of the maximum pressure valves without
authorization from ALMAC S.r.l. will void the warranty and any claims made by
the customer.
3.5.2 Hydraulic block safety devices
The hydraulic block features three solenoid valves with possible manual by-pass.
These solenoid valves, indicated with 1-2-3, are part of the safety system of the
machine and must never be operated manually.
