PAGE 47 ALMAC s.r.l.
3.5 Hydraulic system safety devices
3.5.1 Hydraulic pressure limiting devices
The hydraulic system of the machine has appropriate general maximum pressure
valves (1-2) in order to limit the pressures relative to the operation of the
machine, preserving the integrity of the various components.
These valves do not require adjustments as they are calibrated directly by
ALMAC S.r.l. At the testing phase. The diagram below illustrates the integrated
power pack and the position of the pressure relief valves described above.
