PAGE 79 ALMAC s.r.l.
6.2.4 Checking the hydraulic tank oil level and topping up if necessary
The hydraulic oil level is checked by means of a level indicator located directly
on the tank.
6.2.5 Hydraulic reservoir oil change
The hydraulic oil in the tank must be changed with the frequency indicated in
the general chart.
1. Collect the used oil in a suitable vessel and dispose of it in the proper
way.
2. Empty the tank using the dedicated cap located under the tank (1).
