PAGE 94 ALMAC s.r.l.
- Oil filling caps (4);
- Oil level indicator (1).
[Low end of the oil dipstick]
The engine oil level is appropriate if it is within the range between (2) and (3).
4. If the oil level is too low, remove the oil cap and add oil until it reaches the prescribed
level;
5. Added oil, wait more than 5 minutes and check the level again. This time the oil must
reach the sump.
6.2.13.1.2 Engine oil quantity
IMPORTANT:
Use only the specified engine oil to avoid engine damage.
Other oils could affect the warranty coverage, cause the seizure of internal
engine components and/or shorten the life of the engine.
6.2.13.1.3 Engine oil change
ATTENTION:
To avoid personal injury:
• Be sure to turn off the engine before changing the engine oil;
• When the engine oil drips, place a container under the engine and proceed with
disposal according to local regulations;
• Do not drain the oil after running the engine. Allow the engine to cool sufficiently.
1. Change the oil after the first 50 hours of initial operation, thereafter every 100 hours;
2. Remove the oil drain cap located on the bottom of the engine and drain all the used oil.
Oil drainage is easier and more complete if it is carried out when the engine is hot;
- Oil drain screw cap (1).
3. Add new engine oil to the upper level of the oil level indicator.
