PAGE 95 ALMAC s.r.l.
6.2.13.1.4 Replacing the oil filter cartridge
ATTENTION:
To avoid personal injury:
• Change the oil filter cartridge only when the engine is off;
• Allow the engine to cool sufficiently; the oil can be very hot and burn.
1. Change the oil filter cartridge after the first 50 hours of initial operation, thereafter
every 200 hours;
2. Remove the used filter cartridge using a key;
3. Lightly oil the gasket for the new cartridge;
4. Tighten the cartridge by hand. When the seal comes into contact with the sealing
surface, tighten the cartridge as much as necessary and always by hand. This is because
using a key the cartridge would be overly tightened;
5. After the cartridge has been replaced, the oil level usually lowers a little. For this
reason, run the engine for a while and check for oil leaks from the seal before checking
the oil level. If necessary, add oil.
NOTE: Completely remove any oil stuck to the machine.
6.2.13.1.5 Checking the motor belt
ATTENTION
To avoid personal injury:
• Be sure to turn off the engine before checking the engine belt;
1. The correct tensioning of the belt can be verified through three positions (A), (B) and (C);
