SEED SPECTOR LRX MANUAL
9
Press the EXE key to accept the stable raw data value. After the value has been
accepted, the SS-LRX will be advance to the next weight value. The ‘WGT 1’ indicates
the same data curve is being calibrated and the ‘New 2’ represents the second point of
the calibration.
WGT 1 New 2
[ 0.00] 0000
Enter the value of the second weight in the left side of the display and press the right
arrow key. Position the known weight in the bucket, so the force of the weight is directly
over the load cell or beam. If the weight isn’t position on the bucket properly, calibration
inaccuracies can occur from bucket tension.
WGT 1 New 2
10.02 [ 0000 ]
Press the right arrow again and the raw data will appear on the right side of the display.
The value is not a real-time reading, so the right arrow button needs to be pressed again
to verify a stable value being displayed.
WGT 1 New 2
10.02 [ 2987 ]
Press the EXE key to accept the stable raw data value. When the calibration process is
complete, press ESC key three times to return to the Main Menu.
MANUAL ENTRY
Use the same procedure described for the moisture calibration to manually enter the
weight calibration. If you plan to use a manual calibration entry, you must write down the
values while you are calibrating, view the file after you are done calibrating, or have an
electronic copy of the file.
TEST WEIGHT CALIBRATION
‘TWT1’ and ‘TWT2’ are the designations for the test weight load cells. Calibrating the test
weight is comparable to calibrating the weight channels. Refer to the WEIGHT
CALIBRATION section and select ‘TWT1’ and ‘TWT2’ appropriately at the Data Type
Menu.
