24
$S – SET RELAY
Syntax: $S(N)
Where:
(N) is the relay number
This command sets or closes the specified relay.
SSV Compatibility Strategy
To remain compatible with existing SS COMM S/W, the parameter N will be a
number between 0 and 9 and will be mapped to a specific Device as follows:
Device
(D)
Nickname IRB
Slot(1)
XRB Slot(6)
0
RLY 1 b0 b0
1 RLY 2 b1 b1
2 RLY 3 b2 b2
3 RLY 4 b3 b3
4 RLY 5
NA
b4
5 RLY 6
NA
b5
6 RLY 7
NA
b6
7 RLY 8
NA
b7
8 RLY 9
NA
b8
9 RLY 10
NA
b9
To direct the command to the IRB vs. the XRB DIP-switch 7 (value=64) will be
assigned to indicate the presence of each component. $S and $Z functionality
will be as described below for the following configurations:
• If an IRB is present (DIP-switch 7 on) then the $S and $Z commands will
actuate RLY 1-4. Commands to actuate RLY 5-10 will be ignored
• If and XRB is present (DIP-switch 7 off) then the $S and $Z commands will
actuate RLY 1-10.
Response: None
