Pro, Solo
INSTRUCTION MANUAL Page 6
SHAW-ALMEX INDUSTRIES LIMITED 49908-042 March 2012
2. The cooling water may discharge from the platen initially as steam creating a burning hazard. Ensure the cooling
water discharge is not directed at any person or injury could result.
3. Improper use or component failure could result in the vulcanizer overheating. Always use an Almex temperature
controller when operating the vulcanizer and never leave the vulcanizer operating while unattended.
3.1.4. Electrical Hazard
1. A qualified electrician should perform all maintenance of the electrical components of the vulcanizer.
2. All of the electrical components contain live circuits. Do not open or service any of the electrical equipment
without disconnecting the main power supply.
3. Incorrect voltage and phase may result in component damage and create a fire hazard. Refer to the serial plate
for power specifications.
4. Equipment power supplies must be properly grounded or a severe shocking hazard may result.
5. Avoid using equipment in wet surroundings or a severe shocking hazard may result.
6. If any cable or connectors are damaged, they must be replaced or a fire and shock hazard may result.
3.2. Limitation of use
This equipment has been designed to vulcanize conveyor belts. Applying a combination of heat and pressure on the
product for a certain period of time accomplishes the vulcanizing process. The Pro 60 press operates up to 60 psi
(420 kPa), the Pro 100 and Solo operate up to 100 psi (700 kPa). There is a safety pressure valve built into the air
control assembly that must be used. A continuous pressure supply must not be connected to the press. The platens
can be operated at temperatures up to 325 °F (165 °C). The press is to be connected to an ALMEX temperature
control panel that is supplied complete with platen electrical cables. The press must never be allowed to operate
while unattended. Hoses have been provided to connect a cooling supply to the press. Other use is not allowed
without the written permission of Shaw-Almex.
3.3. Hazardous Materials and Products
The cooling water may discharge from the platen initially as steam creating a burning hazard. Ensure the cooling
water discharge is not directed at any person or injury could result.
Compressed air is generally used to pressurize the press. Never direct compressed air flow at a person. Never
connect the vulcanizer to a continuous air supply.
3.4. Safe Handling
Handling the machine does present some residual hazard. The weight of the components is marked on the serial
plate. Handles are provided on the frames. For the bigger presses, hoisting equipment is needed to position the top
frame in place. Hoisting provision is on the frame.
Wear protective footwear when handling the press.
Connection of cables and hoses must be made in such a way that no tripping hazard is created.
