Alpha CD13R, 18R, 24R - Short Parts List
11 SHORT PARTS LIST
Reference
Burner - CD 13R/18R
Burner - CD 24R
Main injector NG 5.1 mm - CD 13R/18R
Main injector NG 5.25 mm - CD 24R
Main injector LPG 4.0 mm - CD 13R/18R/24R
Primary heat exchanger - CD 13R/18R
Primary heat exchanger - CD 24R
Gas valve - Dungs
Fan assembly
PCB
Flue thermostat (102°C)
Ignition generator
Transformer
Temperature sensor
Fuse F2 A
PCB fuse F315 mA
Overheat thermostat (90°C)
Ignition electrode and lead
Ignition electrode
Flame sensing electrode and lead
Combustion chamber insulation panel front
Condensate trap
Description
British Gas GC No.
H28-392
E94-407
H28-393
H28-394
H28-395
H28-396
H28-397
E94-413
E94-414
E94-415
E76-317
E76-378
E96-571
H28-398
E94-417
E94-418
E96-572
E94-420
Alpha Pt. No.
1.021877
1.013172
1.022472
1.022709
1.021521
1.019725
1.018808
1.021206
1.027267
1.023071
1.018162
1.012477
1.015970
1.6098
1.013931
1.010952
3.013626
1.016779
1.019293
1.014732
3.016875
Qty.
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
Fig. 7.2
Fig. 7.2
Fig. 2.3
Fig. 2.3
Fig. 2.3
Fig. 7.5
Fig. 7.5
Fig. 5.3
Fig. 7.1
Fig. 7.4
Fig. 7.3
Fig. 7.3
Fig. 7.3
Figs. 2.3 and 7.3
Fig. 20
Fig. 7.4
Fig. 7.3
Fig. 7.3
Fig. 7.2
Fig. 27.3 and Fig. 7.2
Fig. 7.2
Fig. 4.4
