DOCNUMBER 9500
Document Issue 1, Revision 7
June 2009 Page 3–3
Alpha Radio Products Alpha 9500 HF Linear Amplifier Operating Manual
Product Release 1 Installation Overview
3.5 Connect the Cables
SEE . . . Section 5.4, “Connect the Cables,” page 5–7
Step 1 Connect the power cord.
Step 2 Adjust the 8877 tube and exhaust chimney.
Step 3 Replace the amplifier cover and all attachment screws.
Step 4 Place the amplifier in its operating position on a stable surface with
sufficient space to the rear, sides, and top to allow good air flow and safe
placement of cables.
Step 5 Connect the amplifier RF INPUT to the transceiver RF OUTPUT.
Step 6 Connect the amplifier RF OUTPUT to the antenna.
Step 7 Connect the transceiver (T/R) control cable to the amplifier.
3.6 Set the Input Drive
SEE . . . Section 5.5, “Set the Input Drive,” page 5–10
Step 1 [need info]
3.7 Connect the Transceiver
SEE . . . Section 5.6, “Connect the Transceiver,” page 5–10
Step 1 Connect the transceiver.
Step 2 (Optional) Enable the transceiver automatic antenna tuner.
