5 1 Introduction
Alpha Technologies
1.3 The Pinnacle Plus Series
1.3.1 Front Panel
These drawings are used for illustrative purposes only. See your unit for the exact location and
type of all switches and controls.
The control panel’s operation is described in Section 3.2.
Figure 1.1
Front Panel
Control Panel
Cooling Vents
(Must not be blocked)
