Alpha Pinnacle Plus Series - Rear Panel

1 Introduction
6
Alpha Technologies
1.3 The Pinnacle Plus Series (Continued)
1.3.2 Rear Panel
These drawings are used for illustrative purposes only. See your unit for the exact location and
type of all connectors, switches and circuit breakers.
Figure 1.2
6 KVA Model
(With Isolation Transformer)
Bypass switch
Input and
Output Circuit
Breakers
External
Battery
Connector
Network
Transient
Protector
Input/Output Connectors
(Factory Configured to Your
Specifications)
Cooling Fans
Optional Interface EPO RS-232 Optional USB Port
Figure 1.1
6 KVA Model
(Without Isolation Transformer)
Bypass switch
Input and
Output Circuit
Breakers
External
Battery
Connector
Network
Transient
Protector
Optional Interface EPO RS-232 Optional USB Port
Input/Output
Connectors
(Factory
Configured to Your
Specifications)
Cooling Fans
