Alpha Pinnacle Plus Series - Page 13

7 1 Introduction
Alpha Technologies
1.3 The Pinnacle Plus Series (Continued)
Figure 1.4
8-10 KVA Model
(With Isolation Transformer)
Bypass switch
Input and
Output Circuit
Breakers
RS-232
Optional
Interface
Cooling Fans
EPO
Network
Transient
Protector
External
Battery
Connector
Input/Output
Connectors
(Factory
Configured to
Yo ur
Specifica-
tions)
Optional UPS Port
Figure 1.3
8-10 KVA Model
(Without Isolation Transformer)
Bypass switch
Input and
Output Circuit
Breakers
External
Battery
Connector
Network
Transient
Protector
Optional
Interface
Cooling Fans
Input/Output
Connectors
(Factory
Configured to Your
Specifications)
Optional
UPS Port
EPO RS-232
