Alpine CDA-118M User Manual

21-EN
Turning Subwoofer ON/OFF
When the subwoofer is on, you can adjust the subwoofer output level
(refer to page 20).
For this unit, the following setting can be made only when the
IMPRINT audio processor (PXA-H100) is not connected.
1 Press and hold AUDIO for at least 2 seconds to
activate the AUDIO selection mode.
2 Turn the Rotary encoder to select the SUBW
mode, and then press
/ENTER.
SUBW SUBW SYSTEM*
1
BASS TREBLE
HPF SUBW
*
1
Displayed only when subwoofer is ON.
3 Turn the Rotary encoder to select SUBW ON/OFF,
and then press
/ ENTER.
ON OFF
4 Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
Setting the Subwoofer System
When the subwoofer is on, you can select either SYS 1 or SYS 2 for the
desired subwoofer effect.
For this unit, the following setting can be made only when the
IMPRINT audio processor (PXA-H100) is not connected.
1 Press and hold AUDIO for at least 2 seconds to
activate the AUDIO selection mode.
2 Turn the Rotary encoder to select the SUBW
SYSTEM mode, and then press
/ ENTER.
SUBW SUBW SYSTEM*
1
BASS TREBLE
HPF SUBW
*
1
Displayed only when subwoofer is ON.
3 Turn the Rotary encoder to select the SUBW SYS 1
or SUBW SYS 2, and then press
/ ENTER.
SYS 1 SYS 2
4 Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
• This function is inoperable when Subwoofer is set to OFF.
Setting the Bass Control
You can change the Bass Frequency emphasis to create your own tonal
preference.
For this unit, the following setting can be made only when the
IMPRINT audio processor (PXA-H100) is not connected.
1 Press and hold AUDIO for at least 2 seconds to
activate the AUDIO selection mode.
2 Turn the Rotary encoder to select the BASS
Adjustment mode, and then press
/ENTER.
SUBW SUBW SYSTEM*
1
BASS TREBLE
HPF SUBW
*
1
Displayed only when subwoofer is ON.
3 -1*
2
Turn the Rotary encoder to select the desired
bass level (–7~+7), and then press
/ ENTER.
You can emphasize or weaken the bass level.
3 -2 Turn the Rotary encoder to select the desired bass
bandwidth, and then press
/ ENTER.
Changes the boosted bass bandwidth to wide or narrow. A
wider setting will boost a wide range of frequencies above
and below the center frequency. A narrower setting will
boost only frequencies near the center frequency.
SYS 1 : Subwoofer level changes according to the main
volume setting.
SYS 2 : Subwoofer level change is different from the main
volume setting. For example, even at low volume
settings, the subwoofer is still audible.
Setting the Bass Level
Setting the Bass Bandwidth

Alpine CDA-118M Specifications

General

MP3 playback	Yes
Audio formats supported	AAC, MP3, WMA
AM band range	530 - 1710 kHz
FM band range	87.7 - 107.9 MHz
Supported radio bands	AM, FM
Clock mode	12h/24h
Product color	Silver
Volume control	Rotary
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Maximum power per channel	50 W
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
Display number of lines	2 lines
Bluetooth	No
USB version	2.0
USB ports quantity	1
File type	FAT 12, 16, 32
Number of optical discs	1 discs
Cables included	USB

Weight and Dimensions

Depth	187 mm
Height	51.5 mm
