Alpine CDA-118M User Manual

22-EN
3 -3 Turn the Rotary encoder to select the desired bass
center frequency, and then press
/ ENTER.
60 (Hz) 80 (Hz) 100 (Hz) 120 (Hz) 60 (Hz)
Emphasizes the displayed bass frequency ranges.
4 Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
• The function is inoperable when DEFEAT is set to ON.
*
2
The adjustment can also be made by pressing IMPRINT. Refer to
“Adjusting Subwoofer/Bass/Treble/Balance (Between Left and
Right)/Fader (Between Front and Rear)/Loudness/Defeat” (page 20).
Setting the Treble Control
You can change the Treble Frequency emphasis to create your own tonal
preference.
For this unit, the following setting can be made only when the
IMPRINT audio processor (PXA-H100) is not connected.
1 Press and hold AUDIO for at least 2 seconds to
activate the AUDIO selection mode.
2 Turn the Rotary encoder to select the TREBLE
Adjustment mode, and then press
/ENTER.
SUBW SUBW SYSTEM*
1
BASS TREBLE
HPF SUBW
*
1
Displayed only when subwoofer is ON.
3 -1*
2
Turn the Rotary encoder to select the desired
treble level (–7~+7), and then press
/ ENTER.
You can emphasize the treble level.
3 -2 Turn the Rotary encoder to select the desired
treble center frequency, and then press
/ ENTER.
10.0 kHz 12.5 kHz 15.0 kHz 17.5 kHz
10.0 kHz
Emphasizes the displayed treble frequency ranges.
4 Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
• The function is inoperable when DEFEAT is set to ON.
*
2
The adjustment can also be made by pressing IMPRINT. Refer to
“Adjusting Subwoofer/Bass/Treble/Balance (Between Left and
Right)/Fader (Between Front and Rear)/Loudness/Defeat” (page 20).
Adjusting the High Pass Filter
The High Pass Filter on this unit can be adjusted to suit your personal
taste.
For this unit, the following setting can be made only when the
IMPRINT audio processor (PXA-H100) is not connected.
1 Press and hold AUDIO for at least 2 seconds to
activate the AUDIO selection mode.
2 Turn the Rotary encoder to select the HPF
Adjustment mode, and then press
/ENTER.
SUBW SUBW SYSTEM*
1
BASS TREBLE
HPF SUBW
*
1
Displayed only when subwoofer is ON.
3 Turn the Rotary encoder to select the desired HPF
frequency, and then press
/ENTER.
OFF 60 (Hz) 80 (Hz) 100 (Hz)
4 Press to return to normal mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
• If is pressed during setting, the unit returns to the previous item.
• The function is inoperable when DEFEAT is set to ON.
Setting the Bass Center Frequency
Setting the Treble Level
Setting the Treble Center Frequency

Alpine CDA-118M Specifications

General

MP3 playback	Yes
Audio formats supported	AAC, MP3, WMA
AM band range	530 - 1710 kHz
FM band range	87.7 - 107.9 MHz
Supported radio bands	AM, FM
Clock mode	12h/24h
Product color	Silver
Volume control	Rotary
Frequency range	5 - 20000 Hz
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Maximum power per channel	50 W
Signal-to-Noise Ratio (SNR)	105 dB
Display type	LCD
Display number of lines	2 lines
Bluetooth	No
USB version	2.0
USB ports quantity	1
File type	FAT 12, 16, 32
Number of optical discs	1 discs
Cables included	USB

Weight and Dimensions

Depth	187 mm
Height	51.5 mm
