Alpine CDE-173BT User Manual

21-EN
*10 CALL SOUND, CALLER ID, PB UPDATE, PB ORDER,
AUTO ANS, SPEAKER SL and FW VERSION can be
selected in this mode. For details about these settings, refer to
“BLUETOOTH SETUP” on page 24.
*11 The Hands free phone talk level, ring tone level and
microphone gain level can be adjusted by using this setting.
Changing the settings in the Option mode will also affect the
same settings in the SETUP menu. Refer to “Adjusting the
volume (VOL LV ADJ)” on page 25.
*12 Refer to “Setting the BLUETOOTH sound quality” on
page 25.
*13 While calling, the call sound can be switched between the
unit and mobile phone by using this setting.
This operation can also be done by pressing BAND. Refer to
“Call Switching Operation” on page 28.
*14 While calling, and the Voice Mute is activated, the
microphone input will mute instantly and “VOICE MUTE”
will blink. This operation can also be done by pressing .
Refer to “Muting the microphone input quickly (Voice Mute)”
on page 28.
*15 If there is a waiting call, select this item to display the caller’s
Name and waiting number (1 or 2). Press VIEW and the
display will switch.
*16 Select this item to hang up the call.
Notes
•Press r to return to the previous mode.
• Pressing and holding r for at least 2 seconds will return to normal
mode.
• If no operation is performed for 60 seconds, the unit will return to
normal mode automatically.
* The illustration is for CDE-173BT.
Setting
You can flexibly customize the unit to suit your own preferences and
usage. From the SETUP menu, GENERAL Setting, DISPLAY Setting,
etc., can be modified.
1 Press and hold AUDIOSETUP for at least 2 seconds to
activate the SETUP mode.
2 Turn the Rotary encoder to select the desired item, and
then press ENTER.
(e.g. Select GENERAL)
AUDIO
*1
 GENERAL  DISPLAY  TUNER  iPod 
BLUETOOTH
*2
GENERAL:
MENU LANG  AUX SETUP
*3
 AUX NAME
*4
 PLAY MODE
*5
 DEMO
DISPLAY:
ILLUMINATI
*5
 DIMMER  TEXTSCROLL  SCROLLTYPE
TUNER:
AF
*6
 REGIONAL
*7
 PI SEEK
*8
 FM SET
iPod:
iPod LIST
*1 Refer to “Audio Setup” on page 16.
*2 Refer to “BLUETOOTH SETUP” on page 24.
*3 Not displayed when the current source is AUXILIARY.
*4 Displayed only when AUX SETUP is set to ON.
*5 CDE-174BT/CDE-173BT only.
*6 Refer to “Turning AF (Alternative Frequencies) ON/OFF” on
page 11.
*7 Refer to “Receiving RDS Regional (Local) Stations” on page 12.
*8 Refer to “PI SEEK Setting” on page 12.
3 Turn the Rotary encoder to select a setting item, and then
press ENTER.
(e.g. Select AUX SETUP)
4 Turn the Rotary encoder to change the setting, and then
press ENTER.
(e.g. Select AUX ON or AUX OFF)
SETUP
Use steps 1 to 5 to select one of the SETUP modes to modify.
See the applicable section below for details about the
selected SETUP item.
AUDIO/SETUP
/ENTER

SOURCE/

Rotary encoder
Online-store car audio and autogoods Winauto
winauto.ua

Alpine CDE-173BT Specifications

General

MP3 playback	Yes
Audio formats supported	AAC, MP3, WMA
FM band range	87.5 - 108 MHz
LW band range	153 - 281 kHz
Supported radio bands	FM, LW, MW
Preset stations quantity	20
RDS features	AF, EON, PTY, TA, TP
Product color	Black, Green, Red
Volume control	Rotary
CD changer capacity	1 discs
Disc types supported	CD, CD-R, CD-RW
Audio output channels	4.0 channels
Equalizer bands quantity	3
Signal-to-Noise Ratio (SNR)	65 dB
Display type	LCD
USB version	2.0
Bluetooth version	3.0+HS
Bluetooth profiles	A2DP, AVRCP, HFP, HSP
USB ports quantity	1
Headphone connectivity	3.5mm
Key illumination color	Multi

Weight and Dimensions

Weight	1500 g
Dimensions (WxDxH)	170 x 25 x 46 mm
