ALPINE INE-W920R/INE-W928R QRG 68-21057Z30-A (EN)
16-EN
Owner’s manual Specifications
Specifications
MONITOR SECTION
Screen Size 6.1” (INE-W920R)
8.0” (INE-W928R)
LCD Type Transparent type TN LCD
Operation System TFT active matrix
Number of Picture Elements
1,152,000 pcs.
(800 × 3 × 480)
Effective Number of Picture Elements
99% or more
Illumination System LED
FM TUNER SECTION
Tuning Range 87.5 – 108.0 MHz
Mono Usable Sensitivity 8.1 dBf (0.7 µV/75 ohms)
50 dB Quieting Sensitivity 12 dBf (1.1 µV/75 ohms)
Alternate Channel Selectivity 80 dB
Signal-to-Noise Ratio 65 dB
Stereo Separation 35 dB
Capture Ratio 2.0 dB
MW TUNER SECTION
Tuning Range 531 – 1,602 kHz
Usable Sensitivity 25.1 µV/28 dBf
LW TUNER SECTION
Tuning Range 153 – 281 kHz
Sensitivity (IEC Standard) 31.6 V/30 dBf
USB SECTION
USB requirements USB 1.1/2.0
Max. Power Consumption 1,000 mA
USB Class USB (Play From Device)/
USB (Mass Storage Class)
File System FAT12/16/32
MP3 Decoding MPEG-1/2 AUDIO Layer-3
WMA Decoding Windows Media™ Audio
AAC Decoding AAC-LC format “.m4a” file
Number of Channels 2-Channel (Stereo)
Frequency Response* 5-20,000 Hz (±1 dB)
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Signal-to-Noise Ratio 100 dB
Channel Separation 85 dB (at 1 kHz)
Frequency response may differ depending on the encoder
software/bit rate.
CD/DVD SECTION
Frequency Response 5 – 20,000 Hz (±1 dB)
Wow & Flutter (% WRMS) Below measurable limits
Total Harmonic Distortion 0.008% (at 1 kHz)
Dynamic Range 95 dB (at 1 kHz)
Channel Separation 85 dB (at 1 kHz)
Signal system NTSC/PAL
Horizontal resolution 500 lines or greater
Video output level 1Vp-p (75 ohms)
*
Video S/N ratio DVD: 60 dB
Audio S/N ratio 100 dB
PICKUP
Wave length DVD: 666 nm
CD: 785 nm
Laser power CLASS II
GPS SECTION
GPS Reception frequency 1575.42 ±1 MHz
GPS Reception sensitivity -130 dB max.
BLUETOOTH SECTION
BLUETOOTH Specification Bluetooth V2.1+EDR
Output Power +4 dBm Max. (Power class 2)
Profile HFP (Hands-Free Profile)
OPP (Object Push Profile)
PBAP (Phone Book Access Profile)
A2DP (Advanced Audio
Distribution Profile)
AVRCP (Audio/Video Remote
Control Profile)
GENERAL
Power Requirement 14.4 V DC
(11–16 V allowable)
Operating temperature -4°F to +140°F
(-20°C to + 60°C)
Maximum Power Output 50 W × 4
Output Voltage 2,000 mV/10k ohms (INE-W920R)
4,000 mV/10k ohms (INE-W928R)
Weight 2.26 kg (INE-W920R)
2.76 kg (INE-W928R)
Audio output level (INE-W920R/INE-W928R)
Preout (Front, Rear): 2V/10k ohms (max.) / 4V/10k ohms
(max.)
Preout (Subwoofer): 2V/10k ohms (max.) / 4V/10k ohms
(max.)
AUX OUT: 1.2V/10k ohms / 1.2V/10k ohms
CHASSIS SIZE (INE-W920R/INE-W928R)
Width 178 mm / 178 mm
Height 100 mm / 100 mm
Depth 164.4 mm / 152.2 mm
NOSE SIZE (INE-W920R/INE-W928R)
Width 170 mm / 197 mm
Height 95 mm / 124.4 mm
Depth 18.5 mm / 30.2 mm
Due to continuous product improvement, specifications
and design are subject to change without notice.
The LCD panel is manufactured using an extremely
high precision manufacturing technology. Its effective
pixel ratio is over 99.99%. This means that there is a
possibility that 0.01% of the pixels could be either always
ON or OFF.
•
•
