Precautions
Be sure to disconnect the cable from the (–) battery post
before installing your KCE-635UB. This will reduce any
chance of damage to the unit in case of a shortcircuit.
• Be sure to connect the color coded leads according to the
diagram. Incorrect connections may cause the unit to
malfunction or damage the vehicle’s electrical system.
• When making connections to the car’s electrical system, be
aware of the factory installed components (e.g. on-board
computer). Do not tap into these leads to provide power for
this unit. When connecting the KCE-635UB to the fuse box,
make sure the fuse for the intended circuit of the KCE-
635UB has the appropriate amperage. Failure to do so may
result in damage to the unit and/or the vehicle. When in
doubt, consult your ALPINE dealer.
• The KCE-635UB uses female RCA-type jacks for
connection to other units (e.g. amplifier) having RCA
connectors. You may need an adaptor to connect other units.
If so, please contact your authorized ALPINE dealer for
assistance.
Installation
Installing USB Mediaplayer
This USB Mediaplayer can be placed inside the trunk,
on the kick panel of the front passenger’s seat or
underdash. However, to avoid unnecessary signal
wiring, it is better to mount the device as close as
possible to the Display.
DO NOT MOUNT THE UNIT IN LOCATIONS
THAT WILL BE IN THE VICINITY OF MOISTURE
OR EXTREME HEAT (such as the engine
compartment).
11-EN
EN
Installation and Connections
Package Contents
• KCE-635UB
• IR Remote Controller (RUE-4230)
• Power Cable (2.0m)
• AV Cable (2m)
• USB Extension Cable (1.5m)
• Installation Screws (4x)
• Owner’s Manual
To Next Page
