CONTENTS
WARNING
................................................................................
1
SERVICE
CARE
.......................................................................
2
ACCESSORIES
........................................................................
2
INSTALLATION
.......................................................................
3
ATTACHING
THE
TOP
COVER
AND
LOGO
PLATE
.......
4
CONNECTIONS
.....................................................................
5
CONNECTION
CHECK
LIST
................................................
8
SWITCH
SETTINGS
...............................................................
9
SYSTEM
DIAGRAMS
.........................................................
11
SPECIFICATIONS
................................................................
14
WARNING
Points
to
Observe for Safe
Usage
Read
this manual carefully before using the system
components. They contain instructions on how to
use
this product in a
safe
and effective manner.
Alpine cannot be responsible for problems
resulting from failure
to
observe the instructions in
this manual.
.&WARNING
This
symbol
means
important
instructions
.
Failure
to
heed
them
can
result
in
serious
injury
or
death.
DO
NOT
OPERATE
ANY FUNCTION
THAT
TAKES
YOUR
ATTENTION
AWAY
FROM
SAFELY
DRIVING
YOUR
VEHICLE.
Any function
that
requires
your
prolonged attention
should only be performed after
coming
to
a complete
stop. Always stop the vehicle in a safe location before
performing these functions. Failure
to
do
so
may result in
an accident.
KEEP
THE
VOLUME
AT
A
LEVEL
WHERE
YOU
CAN
STILL
HEAR
OUTSIDE
NOISES
WHILE DRIVING.
Excessive volume levels
that
obscure sounds such
as
emergency vehicle sirens or road warning signals (train
crossings, etc.) can be dangerous and may result in
an
accident.
LISTENING
AT
LOUD
VOLUME
LEVELS
IN
A
CAR
MAY
ALSO
CAUSE
HEARING
DAMAGE.
DO
NOT
DISASSEMBLE
OR
ALTER.
Doing
so
may result in an accident, fire
or
electric shock.
English
USE
THIS
PRODUCT
FOR
MOBILE 12V
APPLICATIONS.
Use
for
other
than its designed application may result in
fire, electric shock
or
other injury.
USE
THE
CORRECT
AMPERE
RATING
WHEN
REPLACING
FUSES.
Failure
to
do
so
may result in fire
or
electric shock.
DO
NOT
BLOCK
VENTS
OR
RADIATOR
PANELS.
Doing
so
may cause heat
to
build
up
inside and may result
in fire.
MAKE
THE
CORRECT
CONNECTIONS.
Failure
to
make
the
proper connections may result in fire
or
product
damage.
USE
ONLY
IN
CARS
WITH A 12
VOLT
NEGATIVE
GROUND.
(Check
with
your
dealer
if
you are
not
sure.)
Failure
to
do
so
may result in fire, etc.
BEFORE
WIRING, DISCONNECT
THE
CABLE
FROM
THE
NEGATIVE
BATTERY
TERMINAL
Failure
to
do
so
may result in electric shock or injury due
to
electrical shorts.
DO
NOT
ALLOW
CABLES
TO
BECOME
ENTANGLED
IN
SURROUNDING
OBJECTS.
Arrange wiring and cables in compliance
with
the manual
to
prevent obstructions when driving. Cables
or
wiring
that
obstruct
or
hang
up
on places such
as
the
steering
wheel, gear lever, brake pedals, etc. can be extremely
hazardous.
DO
NOT
SPLICE
INTO
ELECTRICAL
CABLES.
Never cut away cable insulation
to
supply
power
to
other
equipment. Doing
so
will exceed the current carrying
capacity
of
the
wire and result in fire or electric shock.
DO
NOT
DAMAGE
PIPE
OR
WIRING
WHEN
DRILLING
HOLES.
When drilling holes in
the
chassis for installation, take
precautions
so
as
not
to
contact, damage
or
obstruct
pipes, fuel lines, tanks
or
electrical wiring. Failure
to
take
such precautions may result in fire.
1-EN
