SPECIFICATIONS
S2-A36F
Performance
Power Output
Per Channel, Ref.: 4 Ω, 14.4 V 60 W RMS × 4
Per Channel, Ref.: 2 Ω, 14.4 V 90 W RMS × 4
Bridged, Ref.: 4 Ω, 14.4 V 180 W RMS × 2
THD+N
Ref.: 10 W into 4 Ω ≤0.03%
Ref.: 10 W into 2 Ω ≤0.05%
Ref.: Rated Power into 4 Ω ≤0.08%
Ref.: Rated Power into 2 Ω ≤0.1%
S/N Ratio
IHF A-wtd + AES-17
Ref.: 1 W into 4 Ω
>83 dB
IHF A-wtd + AES-17
Ref.: Rated Power into 4 Ω
>98 dB
Frequency Response
+0/−3 dB, Ref.: 1 W into 4 Ω
10 Hz - 4
0 kHz
+0/−1 dB, Ref.: 1 W into 4 Ω 20 Hz - 20 kHz
Damping Factor Ref.: 10 W into 4 Ω at 100 Hz >100
Control
Input Sensitivity
RCA Input
Ref.: Rated Power into 4 Ω
Hi: 0.5 - 10 V
Lo: 0.2 - 4.0 V
Crossover Variable HPF/LPF
50 Hz - 400 Hz
(−12 dB/oct.)
Remote Level* Linear Attenuation
CH-3/4:
0 to −20 dB
General
Input Impedance >10 kΩ
Dimensions
Width 220 mm (8-11/16”)
Height 56.5 mm (2-1/4”)
Depth 210 mm (8-1/4”)
Weight 2.2 kg (4 lb 13 oz)
* Requires optional RUX-KNOB.2.
NOTE:
• Specifications and design are subject to change without notice.
S2-A55V
CH-1/2/3/4 SUBWOOFER
Performance
Power Output
Per Channel, Ref.: 4 Ω, 14.4 V 40 W RMS × 4 200 W RMS × 1
Per Channel, Ref.: 2 Ω, 14.4 V 60 W RMS × 4 300 W RMS × 1
Bridged, Ref.: 4 Ω, 14.4 V 120 W RMS × 2 –
THD+N
Ref.: 10 W into 4 Ω ≤0.03% ≤0.03%
Ref.: 10 W into 2 Ω ≤0.05% ≤0.05%
Ref.: Rated Power into 4 Ω ≤0.07% ≤0.07%
Ref.: Rated Power into 2 Ω ≤0.1% ≤0.1%
S/N Ratio
IHF A-wtd + AES-17
Ref.: 1 W into 4 Ω
>83 dB >83 dB
IHF A-wtd + AES-17
Ref.: Rated Power into 4 Ω
>98 dB >98 dB
Frequency Response
+0/−3 dB, Ref.: 1 W into 4 Ω 50 Hz - 30 kHz 10 Hz - 400 Hz
+0/−1 dB, Ref.: 1 W into 4 Ω 60 Hz - 20 kHz 20 Hz - 300 Hz
Damping Factor Ref.: 10 W into 4 Ω at 100 Hz >100 >750
Control
Input Select
Selectable Input Signal
Configuration (2ch/4ch Input)
CH-3/4:
CH-1/2 or CH-3/4
CH-1+2+3+4
or SUB
Input Sensitivity
RCA Input
Ref.: Rated Power into 4 Ω
Hi: 0.5 - 10 V
Lo: 0.2 - 4.0 V
Hi: 0.5 - 10 V
Lo: 0.2 - 4.0 V
Crossover Variable HPF/LPF
HPF: 50 Hz - 400 Hz
(−12 dB/oct.)
LPF: 50 Hz - 400 Hz
(−24 dB/oct.)
Remote Level* Linear Attenuation – 0 to −20 dB
General
Input Impedance >10 kΩ
Dimensions
Width 302 mm (11-7/8”)
Height 56.5 mm (2-1/4”)
Depth 210 mm (8-1/4”)
Weight 3.2 kg (7 lb)
* Requires optional RUX-KNOB.2.
NOTE:
• Specifications and design are subject to change without notice.
