16
Error description Error code
Stored code in
E
2
PROM (select “ 0d ”
in CAL mode)
1
Codes for System Fault
For this kind of problems, ask for the technical assistance, after having checked the signal by switching off and on the unit
Errors related to Master microcontroller
RAM Memory
Err 32 20
FLASH Memory
Err 34 22
System complemented variables
Err 35 23
Watchdog Timer
Err 33 21
Errors related to power supply section
+5VDC failure
Err 36 24
HF power supply failure with lower setting value
Err 37 25
HF power supply failure with higher setting value
Err 38 26
HF power supply higher than setting value during activation
Err 97 61
Errors related to serial communication
Failure regarding serial communication peripheral placed on mother board alsa code
801463
2 slow sound
repeatitions; after
fast repeatitions
3d
Failure regarding serial communication peripheral placed on power supply board alsa
code 801471
3 slow sound
repeatitions; after
fast repeatitions
3E
Failure regarding serial communication peripheral placed on double handswitch & nP
control board alsa code 801462
4 slow sound
repeatitions; after
fast repeatitions
3F
E
2
PROM Communication error
5 slow sound
repeatitions; after
fast repeatitions
40
I
2
CBUS connection lost (during the use)
6 slow sound
repeatitions; after
fast repeatitions
43
Master-Slave connection lost (during selftest phase)
7 slow sound
repeatitions; after
fast repeatitions
41
Slave microcontroller failure
8 slow sound
repeatitions; after
fast repeatitions
44
Errors related to Slave microcontroller
Failure in a Slave microcontroller internal peripheral
Err 60 3C
Slave microcontroller connection failed
Err 68 44
Errors related to HF power section
Failure in internal dummy load used for selftest
Err 39 27
Failure in HF output current measurement (lower than expected)
Err 51 33
Failure in HF output current measurement (higher than expected)
Err 52 34
Failure in bipolar output power( lower than expected)
Err 43 2b
Failure in bipolar output power( higher than expected)
Err 42 2A
Failure in monopolar circuit when PURE cut mode is used
Err 40 28
Failure in monopolar circuit when SPRAY mode is used
Err 41 29
Failed modulation signal for monopolar BLEND-1 mode
Err 44 2C
Failed modulation signal for monopolar FULG FORCED mode
Err 45 2d
Failed modulation signal for monopolar SPRAY mode
Err 46 2E
Output peak voltage reading failed (lower than expected)
Err 47 2F
Output peak voltage reading failed (higher than expected)
Err 48 30
Output peak current reading failed (lower than expected)
Err 49 31
Output peak current reading failed (higher than expected)
Err 50 32
HF output power higher than expected
Err 98 62
Errors related to thermal protection
Power supply thermal protection
Err 27 1b
HF power section thermal protection
Err 28 1C
