COMBINATED CUT (CUT ALTERNATED TO COAGULATION) (ENDO) – For flexible endoscopy with cutting phases
alternated to coagulation phases
This is a constant voltage current and it is controlled by aspecial automatic power self adjustment system (ADC System)
according to the characteristics of the tissues.
Control devices to be used (area C):
- With the selection key, select the current ENDO, then adjust the power with the regulation keys;
- For the delivery (loud acoustic signal, and yellow Led), press on the yellow pedal of the foot-switch pedal, or the yellow key of the
hand-switch handle.
Instructions for use, adjustments and electrodes
Ideal only for flexible endoscopic surgery (i.e. polipectomy or papillotomy).
CURRENTS for COAGULATION
“FULGURATION” COAGULATION (FULG FORCED) – Strong superficial sparkling effect, and optimum deep coagulating effect
This current guarantees a strong coagulating effect, both deep and superficial, and therefore it is suitable both for coagulations performed
with forceps/surgical instrument, and for coagulations performed by grazing the tissues with the active electrode.
This current is controlled by an automatic system (ADC System) for the self regulation of the functioning, which guarantees that the power
selected by the operators remains constant according to the characteristics of the tissues.
Control devices to be used (area D):
- With the selection key, select the current FULG FORCED, then adjust the power with the regulation keys;
- For the delivery (acute acoustic signal, and blue Led), press on the blue pedal of the twin foot-switch pedal, or the blue key of the
hand-switch electrodes-holder handle. It is also possible to deliver the current by simply closing the coagulation forceps, just in case a
hand-switch forceps is used (PMI/P or PMI/B).
Instructions for use, adjustments and electrodes
It can be used with all types of electrodes (ball, blade, or needle type, insulated coagulation forceps, loop electrodes in conization,
hook electrodes, dissectors, and forceps in laparoscopy) from 40-50W.
“PIN POINT CONTACT” COAGULATION (PIN POINT CONTACT) – Medium-Low superficial sparkling effect, and optimum
deep coagulating effect
This current guarantees a strong deep coagulating effect and a normal superficial coagulating effect. It is suitable both for coagulations
performed with forceps/surgical instrument and for coagulations performed directly with the active electrode, just in case the operators
prefer a superficial effect which is less strong than the one of the FULG FORCED coagulation.
This current is controlled by an automatic system (ADC System) for the self regulation of the functioning, which guarantees that the power
selected by the operators remains constant according to the characteristics of the tissues.
Control devices to be used (area D):
- With the selection key, select the current PIN POINT CONTACT, then adjust the power with the regulation keys;
- For the delivery (acute acoustic signal, and blue Led), press on the blue pedal of the twin foot-switch pedal, or the blue key of the
hand-switch electrodes-holder handle. It is also possible to deliver the current by simply closing the coagulation forceps, just in case a
hand-switch forceps is used (PMI/P or PMI/B).
Instructions for use, adjustments and electrodes
It can be used with all types of electrodes (ball, blade, or needle type, insulated coagulation forceps, loop electrodes in conization,
hook electrodes, dissectors, and forceps in laparoscopy) from 40-50W.
“SOFT” COAGULATION (SOFT) – Low superficial sparkling effect, and good deep coagulating effect
This current guarantees a good deep coagulating effect, and a very low superficial coagulating effect. It is suitable above all
for the
coagulations performed with forceps/surgical instrument, and for coagulations performed by touching the tissues with an active ball
electrode of at least 4-5mm.
This current is controlled by an automatic system (ADC System) for the self regulation of the functioning, which guarantees that the power
selected by the operators remains constant according to the characteristics of the tissues.
Control devices to be used (area D):
- With the selection key, select the current SOFT, then adjust the power with the regulation keys;
- For the delivery (acute acoustic signal, and blue Led), press on the blue pedal of the twin foot-switch pedal, or the blue key of the
hand-switch electrodes-holder handle. It is also possible to deliver the current by simply closing the coagulation forceps, just in case a
hand-switch forceps is used (PMI/P or PMI/B).
Instructions for use, adjustments and electrodes
Use coagulation electrodes (ball type, coagulation insulated forceps in laparoscopy) from 50-60W.
“SPRAY” COAGULATION (SPRAY) – Very strong superficial sparkling effect, and good deep coagulating effect
This current guarantees a good deep coagulating effect, and a very strong superficial coagulating effect. It is suitable both for the
coagulations performed with forceps/surgical instrument, and for coagulations performed directly with the active electrode, even far away
from the tissues.
This current is controlled by an automatic system (ADC System) for the self regulation of the functioning, which guarantees that the power
selected by the operators remains constant according to the characteristics of the tissues.
Control devices to be used (area D):
- With the selection key, select the current SPRAY, then adjust the power with the regulation keys;
- For the delivery (acute acoustic signal, and blue Led), press on the blue pedal of the twin foot-switch pedal, or the blue key of the
hand-switch electrodes-holder handle. It is also possible to deliver the current by simply closing the coagulation forceps, just in case a
hand-switch forceps is used (PMI/P or PMI/B).
Instructions for use, adjustments and electrodes
Use cutting and coagulation electrodes (blade, needle, ball type, and coagulation insulated forceps, in laparoscopy,
