“PIN POINT CONTACT” COAGULATION AT MEDIUM VOLTAGE (PIN POINT CONTACT) – Medium-Low superficial
sparkling effect, and optimum deep coagulating effect
This current guarantees a strong deep coagulating effect, and a normal superficial coagulating effect. It is suitable both for coagulations
performed with forceps/surgical instrument, and for coagulations performed by grazing the tissues with the active electrode, just in case the
operators prefer a superficial effect which is less strong than the one of the FULG FORCED coagulation.
This current is controlled by an automatic system (ADC System) for the self regulation of the functioning, which guarantees that the power
selected by the operators remains constant according to the characteristics of the tissues.
Control devices to be used (area D):
- With the selection key, select the current PIN POINT CONTACT, then adjust the power with the regulation keys;
- For the delivery (acute acoustic signal, and blue Led), press on the blue pedal of the twin foot-switch pedal.
Instructions for use, adjustments and electrodes
Use the flexible electrodes of the endoscopes, from 20-30W.
“SOFT” COAGULATION AT LOW VOLTAGE (SOFT) – Low superficial sparkling effect, and good deep coagulating effect
This current guarantees a good deep coagulating effect, and a very low superficial coagulating effect. Is suitable above all for coagulations
performed with forceps/surgical instrument, and for coagulations performed by touching the tissues with an active ball electrode of 4-5mm
at least.
This current is controlled by an automatic system (ADC System) for the self regulation of the functioning, which guarantees that the power
selected by the operators remains constant according to the characteristics of the tissues.
Control devices to be used (area D):
- With the selection key, select the current SOFT, then adjust the power with the regulation keys;
- For the delivery (acute acoustic signal, and blue Led), press on the blue pedal of the twin foot-switch pedal.
Instructions for use, adjustments and electrodes
Use the flexible electrodes of the endoscopes, from 30-40W.
“SPRAY” COAGULATION AT VERY HIGH VOLTAGE (SPRAY) – Very strong superficial sparkling effect, and good deep
coagulating effect
This current guarantees a good deep coagulating effect, and a very strong superficial coagulating effect. It is suitable both for the
coagulations performed with forceps/surgical instrument, and for coagulations performed directly with the active electrode, even far away
from the tissues.
This current is controlled by an automatic system (ADC System) for the self regulation of the functioning, which guarantees that the power
selected by the operators remains constant according to the characteristics of the tissues.
Control devices to be used (area D):
- With the selection key, select the current SPRAY, then adjust the power with the regulation keys;
- For the delivery (acute acoustic signal, and blue Led), press on the blue pedal of the twin foot-switch pedal.
Instructions for use, adjustments and electrodes
Use the flexible electrodes of the endoscopes, from 20-30W.
ADVICE
For the Cut, use as follows:
Current PURE, for a cut without coagulating effect and constant delivery of the power (from 20-30W for papillotomy or polipectomy with
polypus until 5mm, and from 30-40W with polypus 6mm or more);
Current BLEND-1, for a cut with a soft coagulating effect and constant delivery of the power (from 20-30W for papillotomy or polipectomy
with polypus until 5mm, and from 30-40W with polypus 6mm or more);
Current ENDO, for a cut-coagulation combination (alternated phases of cut and coagulation), and self regulation of the power (from 70-80W
for papillotomy or polipectomy with polypus until 5mm, and from 90-100W with polypus 6mm or more).
For the Coagulation, use as follows:
Current FULG FORCED, from 30-40W;
Current PIN POINT CONTACT, from 40-50W, for a superficial effect which is softer than the one of the FULG FORCED coagulation.
FUNCTIONING for the UNDER LIQUID ENDOSCOPIC SURGERY
(TUR, TURP, TURV, etc.)
(See Par. “PROGRAMS and MEMORIES”, program nr. 8).
CONNECTION and USE of the ACCESSORIES
1. Socket (5-PED-1): electrode of the monopolar resectoscope for the use by foot-switch pedal (See Par. “CONNECTION and USE of
the PEDAL FOOT-SWITCHES”).
Use only this socket to connect the above mentioned instrument. The use of different sockets provokes a damage to the unit.
Just in case of a cable with a plug which is different from ALSA standard type, ask for:
- Adaptor (RD/5, for cables with non insulated plugs from 2 to 8mm, or with insulated plug 4mm).
2. Socket (7- N.P.): neutral electrode.
According to the connection possibilities listed above, the unit allows to:
A. Use the resectoscope by foot-switch activation (See Par. “CONNECTION and USE of the PEDAL FOOT-SWITCHES”).
Just press on the yellow pedal for the pure/coagulating cut currents, and on the blue pedal for the coagulation currents.
C. !!! BIPOLAR FUNCTIONING!!!
The bipolar functioning is always possible. See Par. “BIPOLAR MODE”.
