Maintenance
Replacing the FK3--07 operating mechanism
P51--8001EN/02
1/10
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Presentation
Warning
BEFORE ANY INTERVENTION ON THE OPERATING MECHANISM,
MAKE SURE THE CIRCUIT--BREAKER IS OPEN AND THE STATUS OF
THE OPERATING MECHANISM INDICATOR IS AS SHOWN BELOW.
Circuit--breaker
Open
Closing spring
Unarmed
Lifting means
Provide an adequate means of hoisting (60 daN).
Tools required
List of ALSTOM Grid tools required to remove the operating mechanism:
Mark Illustration Description Quantity
(1) Hoisting strap 1
(4)
HOLDING
TOOL
1
Steps for
replacement
The operating mechanism is replaced in several steps:
Step Subject Page
A Safety measures 2
B Deflating the pole 4
C Maintaining the pole coupling sleeve 5
D Disconnecting the low voltage cables 6
E Removing the operating mechanism 7
F Mounting the new operating mechanism 8
G Reinflating the pole 9
To Next Page
