Installation
Hoisting and in stalling the pole
P31--2001EN/03
1/6
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Presentation
Necessary
components
List of ALSTOM Grid items necessary for the operation :
Mark Illustration Description Quantity
(1) Cross--brace 2
(2)
Fittings
H M16-75
4
Tools required
List of tools required for hoisting and installing the pole :
Mark Illustration Description Quantity
(3)
HOISTING
STRAP
(3 m -- 1000 kg)
2
In this module
This module covers the following subjects:
Subject Page
Preparation of the pole 2
Hoisting the pole 3
Installing the pole 4
