Description and Functionalities
Pole operation
(principle of breaking)
P13--0001EN/02
1/6
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Presentation
Introduction
In ”CLOSED” position, the current passes by :
-- the power supply terminal (1),
-- the rod--side contact holder (2),
-- the main contacts (3),
-- the arc contact rod (7),
-- the shaft contact tulip (6),
-- the tulip--side contact holder (4),
-- the opposed power supply terminal (1),
3
2
1
7
6
4
In this module
This module deals with the pole’s operating phases:
Phase Page
Opening 2
Closing 5
