Description and Functionalities
Pole operation
(principle of breaking)
P13--0001EN/02
5/6
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Closing
Description
On electrical or manual order to close, the energy accumulated in the
opening spring (11), located in the operating mechanism, is freed. This
energy is transmitted to the operating shaft (16) of the pole, and ensures
closing.
The liberation of the energy stored in the closing spring (11) causes the
displacement of the mobile components and therefore the closing of the
breaking chamber , as well as resetting the opening spring (10).
8
16
7
6
11
10
