Description and Functionalities
Monitoring of SF
6
gas
P20--0001EN/02
1/6
01--2011
© ALSTOM 2010. All rights reserved. Information contained in this document is indicative only. No representation or warranty is given or should be
relied on that it is complete or correct or will apply to any particular project. This will depend on the technical and commercial circumstances. It is
provided without liability and is subject to change without notice. Reproduction, use or disclosure to third parties, without express written authority, is
strictly prohibited.
GRID
Presentation
Introduction
The circuit breaker uses pressurised SF
6
gas like arc extinguisher gas.
It is therefore indispensible to monitor the SF
6
gas to guaranty the circuit
breaker performance.
Principl e
There are two ways to monitor SF
6
gas pressure:
D Permanent monitoring, using a contact densimeter.
D Periodic monitoring, using a dialled densimeter (visual verification).
Symbols
IEC symbols for the technical characteristics of the equipment.
Symbol Description
p
re
Assigned filling pressure for insulation
p
ae
Alarm pressure for insulation
p
me
Minimum insulation pressure
In this module
This module covers the following subjects:
Subject Page
Pressure and density 2
Calculation of pressure 3
Determination of density 4
Densimeter 5
