Manual Operations
Motor-wound spring operating mechanism FK3-07
for outdoor circuit breaker
26.04.2011
© ALSTOM
• Turn the motor limit switch lever 71.76 approx. 90° clockwise by pulling it
71.77
70.24 71.76 71.75
• with the blocking device of the motor limit switch 71.75.
Illustration 47
Illustration 46
