Controls
Measurement unit
1 Display for user guidance
2 Operatebutton(measurementbutton):switchonandmeasure
3 Indicatorlights
4 Stylus
5 Alignment mark
6 USB-InterfaceforchargingorconnectingtoaPC
7 Pins to detect correct placement during measurement procedure
8 Protective clamp
9 Hand strap ring
4. Controls
1
2
3
4
5
6
7
8
9
