Altana BYK Automatchic Vision User Manual

36
12. Technical Data
General technical data:
Temperature range 0 °C to +60 °C (32 °F to 140 °F )
for storage
+5 °C to +40 °C (41 °F to 104 °F)
for operation
Rel. humidity Up to 85% non-condensing/35°C (95 °F)
Measurement unit:
Geometry   Illumination45°
25°, 45°, 110° aspecular viewing
Measurement aperture 10mm (0.40 in.)
Spectral range 400 - 700 nm
Spectral interval 10 nm
Repeatability < 0.05 dE94-rms
10 consecutive readings on white tile
Inter-instrument  BCRAsolidtileset:dE94-rms<0.15
agreement BCRA solid tile set: dE94max = 0.39
Memory 300 samples
Akkuoperation   5V1.5A;2900mAh;10.4Wh
Dimensions (LxWxH) 164 x 69 x 102mm (6.4 x 2.7 x 4.0 in.)
Weight approx. 460g/ 0.92 lbs
Interface   Micro-USB-B
Technical Data

Altana BYK Automatchic Vision Specifications

General

Brand	Altana
Model	BYK Automatchic Vision
Category	Measuring Instruments
Language	English
