2–28 Chapter 2: Board Components
Components and Interfaces
Cyclone V GT FPGA Development Board August 2017 Altera Corporation
Reference Manual
76 ENET_LED_LINK10 — 2.5-V CMOS 10-Mb link LED
74
ENET_LED_LINK100 — 2.5-V CMOS 100-Mb link LED
73
ENET_LED_LINK1000 — 2.5-V CMOS 1000-Mb link LED
58
ENET_LED_RX — 2.5-V CMOS RX data active LED
69
ENET_LED_RX — 2.5-V CMOS RX data active LED
68
ENET_LED_TX — 2.5-V CMOS TX data active LED
25
ENET_MDC AM8 2.5-V CMOS Management bus data clock
24
ENET_MDIO AG14 2.5-V CMOS Management bus data
28
ENET_RESETN AN9 2.5-V CMOS Device reset
2
ENET_RX_CLK AM10 2.5-V CMOS RGMII receive clock
95
ENET_RX_D0 AK14 2.5-V CMOS RGMII receive data bus
92
ENET_RX_D1 AL10 2.5-V CMOS RGMII receive data bus
93
ENET_RX_D2 AJ14 2.5-V CMOS RGMII receive data bus
91
ENET_RX_D3 AK12 2.5-V CMOS RGMII receive data bus
94
ENET_RX_DV AH14 2.5-V CMOS RGMII receive data valid
11
ENET_TX_D0 AB14 2.5-V CMOS RGMII transmit data bus
12
ENET_TX_D1 AD15 2.5-V CMOS RGMII transmit data bus
14
ENET_TX_D2 AB15 2.5-V CMOS RGMII transmit data bus
16
ENET_TX_D3 AB13 2.5-V CMOS RGMII transmit data bus
9
ENET_TX_EN AC14 2.5-V CMOS RGMII transmit enable
55
ENET_XTAL_25MHZ — 2.5-V CMOS 25-MHz RGMII transmit clock
29
MDI_P0 — 2.5-V CMOS Media dependent interface
31
MDI_N0 — 2.5-V CMOS Media dependent interface
33
MDI_P1 — 2.5-V CMOS Media dependent interface
34
MDI_N1 — 2.5-V CMOS Media dependent interface
39
MDI_P2 — 2.5-V CMOS Media dependent interface
41
MDI_N2 — 2.5-V CMOS Media dependent interface
42
MDI_P3 — 2.5-V CMOS Media dependent interface
43
MDI_N3 — 2.5-V CMOS Media dependent interface
Table 2–21. Ethernet PHY Pin Assignments, Signal Names and Functions (Part 2 of 2)
Board
Reference (U11)
Schematic Signal Name
Cyclone V GT
Pin Number
I/O Standard Description
