• Clock Switchover Parameter Settings on page 6-3
Guideline: .mif Streaming in PLL Reconfiguration
Consider the following guidelines when using .mif streaming in PLL reconfiguration:
• 10M02 devices do not support .mif streaming in PLL reconfiguration due to flash size limitation. Altera
recommends using an external flash.
• 10M04, 10M08, 10M16, 10M25, 10M40, and 10M50 devices only support .mif streaming in single
image mode. Altera recommends using an external flash for dual image mode. The MAX 10 devices do
not support using both dual image mode and PLL reconfiguration with .mif simultaneously.
Related Information
PLL Reconfiguration on page 2-26
Guideline: scandone Signal for PLL Reconfiguration
scandone signal must be low before the second PLL reconfiguration. For scandone signal to go low, PLL
areset signal must be asserted.
