Port Name Condition Description
inclk[] Required
Clock input of the clock buffer.
Input port [1 DOWNTO 0] wide.
You can specify up to two clock inputs, inclk[1..0].
Clock pins, clock outputs from the PLL, and core signals can
drive the inclk[] port.
Multiple clock inputs are only supported for the global clock
networks.
Table 5-3: ALTCLKCTRL Output Ports for MAX 10 Devices
Port Name Condition Description
outclk Required Output of the clock buffer.
Related Information
• Global Clock Control Block on page 2-4
• Global Clock Network Power Down on page 2-6
• Clock Enable Signals on page 2-7
• Guideline: Clock Enable Signals on page 3-1
UG-M10CLKPLL
2015.06.12
ALTCLKCTRL Ports and Signals
5-3
