Table 7-5: counter_param[2..0] Settings for MAX 10 Devices
Counter Type Counter Param Binary Decimal Width (bits)
Regular counters (C0 -
C4)
High count 000 0 8
Low count 001 1 8
Bypass 100 4 1
Mode (odd/even division) 101 5 1
CP/LF
Charge pump unused 101 5 5
Charge pump current 000 0 3
Loop filter unused 100 4 1
Loop filter resistor 001 1 5
Loop filter capacitance 010 2 2
VCO VCO post scale 000 0 1
M/N counters
High count 000 0 8
Low count 001 1 8
Bypass 100 4 1
Mode (odd/even division) 101 5 1
Nominal count 111 7 9
For even nominal count, the counter bits are automatically set as follows:
• high_count = Nominalcount/2
• low_count= Nominalcount/2
For odd nominal count, the counter bits are automatically set as follows:
• high_count = (Nominalcount + 1)/2
• low_count = Nominalcount - high_count
• odd/even division bit = 1
For nominal count = 1, bypass bit = 1.
