IP21 / UL Type 1 Products 3-Phase Power Part Supply 380…480 Vac 50/60 Hz
Catalog Number and
Frame Size (S•)
Nominal Power
(1)
Power Part Supply Drive (output)
Max. Input
Current
Apparent
Power
Max.
Inrush
Current
(2)
Nominal
Current (1)
Max.
Transient
current (1)
(3)
At
380 Vac
At
480 Vac
kW HP A A kVA A A A
ATV630U07N4 S1 0.75 1 1.5 1.3 1.1 8 2.2 2.4
ATV630U15N4 S1 1.5 2 3 2.6 2.2 8.3 4 4.4
ATV630U22N4 S1 2.2 3 4.3 3.8 3.2 8.4 5.6 6.2
ATV630U30N4 S1 3 - 5.8 5.1 4.2 31.5 7.2 7.9
ATV630U40N4 S1 4 5 7.6 6.7 5.6 32.2 9.3 10.2
ATV630U55N4 S1 5.5
7
1/2
10.4 9.1 7.6 33.2 12.7 14
ATV630U75N4 S2 7.5 10 13.8 11.9 9.9 39.9 16.5 18.2
ATV630D11N4 S2 11 15 19.8 17 14.1 40.4 23.5 25.9
ATV630D15N4 S3 15 20 27 23.3 19.4 74.5 31.7 34.9
ATV630D18N4 S3 18.5 25 33.4 28.9 24 75.5 39.2 43.1
ATV630D22N4 S3 22 30 39.6 34.4 28.6 76 46.3 50.9
ATV630D30N4 S4 30 40 53.3 45.9 38.2 83 61.5 67.7
ATV630D37N4 S4 37 50 66.2 57.3 47.6 92 74.5 82
ATV630D45N4 S4 45 60 79.8 69.1 57.4 110 88 96.8
ATV630D55N4 S5 55 75 97.2 84.2 70 176 106 116.6
ATV630D75N4 S5 75 100 131.3 112.7 93.7 187 145 159.5
ATV630D90N4 S5 90 125 156.2 135.8 112.9 236 173 190.3
ATV630C11N4 S6 110 150 201 165 121.8 325 211 232
ATV630C13N4 S6 132 200 237 213 161.4 325 250 275
ATV630C16N4 S6 160 250 284 262 201.3 325 302 332
(1) The switching frequency is adjustable:
z From 1...16 kHz for drive frame sizes 1 to 4, rated value: 4 kHz
z From 1...8 kHz for drive frame sizes 5 and 6, rated value: 2.5 kHz
For operation at switching frequencies higher than the rated value. Derating must be applied to the drive (output)
current (see page 46). In this case, switching frequency can be reduced if an excessive temperature rise occurs.
(2) Peak current when power is switched On, for the maximum supply mains voltage.
(3) The drive is designed to run up to 60 s at 110% of nominal current.
