46 EAV64301 01/2015
Derating Curves
Description
Derating curves for the nominal drive current (In) as a function of temperature and switching frequency.
Frame Size 1 - 200...240 V
Frame Size 1 - 380...480 V
Frame Size 2 - 200...240 V
