EAV64301 01/2015 43
Drive Ratings In Heavy Duty
Heavy Duty
Heavy-duty values are given for applications requiring a significant overload (up to 150 %).
IP21 / UL Type 1 Products 3-Phase Power Part Supply 200…240 Vac 50/60 Hz
Catalog Number and
Frame Size (S•)
Nominal
Power (1)
Power Part Supply Drive (output)
Max. Input Current Apparent
Power
Max.
Inrush
Current
(2)
Nominal
Current (1)
Max.
Transient
current (1)
(3)
At
200 Vac
At
240 Vac
kW HP A A kVA A A A
ATV630U07M3 S1 0.4 1/2 1.7 1.5 0.6 4.3 3.3 5
ATV630U15M3 S1 0.8 1 3.3 3 1.2 4.3 4.6 6.9
ATV630U22M3 S1 1.5 2 6 5.3 2.2 4.3 8 12
ATV630U30M3 S1 2.2 3 8.7 7.6 3.2 17.5 11.2 16.8
ATV630U40M3 S1 3 – 11.7 10.2 4.2 17.6 13.7 20.6
ATV630U55M3 S2 4 5 15.1 13 5.4 30.9 18.7 28.1
ATV630U75M3 S3 5.5
7
1/2
20.1 16.9 7 39.3 25.4 38.1
ATV630D11M3 S3 7.5 10 27.2 23.1 9.6 39.3 32.7 49.1
ATV630D15M3 S4 11 15 40.1 34.3 14.3 64.6 46.8 70.2
ATV630D18M3 S4 15 20 53.1 44.9 18.7 71.3 63.4 95.1
ATV630D22M3 S4 18.5 25 64.8 54.5 22.7 70.9 78.4 117.6
ATV630D30M3 S5 22 30 78.3 67.1 27.9 133.3 92.6 138.9
ATV630D37M3 S5 30 40 104.7 88.6 36.8 133.3 123 184.5
ATV630D45M3 S5 37 50 128.5 108.5 45.1 175 149 223.5
ATV630D55M3 S6 45 60 156 134 50 168.2 176 264
ATV630D75M3 S6 55 75 189 161 61.1 168.2 211 316.5
(1) The switching frequency is adjustable:
z From 1...16 kHz for drive frame sizes 1 to 4, rated value: 4 kHz
z From 1...8 kHz for drive frame sizes 5 and 6, rated value: 2.5 kHz
For operation at switching frequencies higher than the rated value. Derating must be applied to the drive (output)
current (see page 46). In this case, switching frequency can be reduced if an excessive temperature rise occurs.
(2) Peak current when power is switched On, for the maximum supply mains voltage.
(3) The drive is designed to run up to 60 s at 150% of nominal current.
(4) First value is the power dissipated at nominal current in a forced cooled area. The second value in italic is the power
dissipated at nominal current in a natural cooled area, value used in case of installation using the flush-mounting
kit, separate hot and cold part in a cabinet.
