INSTALLATION
Attach tray using two carriage bolts (A) in base
panel. Lift tray up and away to remove.
DRIP TRAY INSTALLATION
A
GREASE COLLECTION UNIT
DESCRIPTION PART NO.
CASTERS, 5" (127mm) 2 rigid, 2 swivel w/ brake 4007
DOOR HANDLE non-control side HD-26900
DOOR OPTIONS siNgle PaNe flat glass, coNtrol side (rH uNits)
siNgle PaNe flat glass, NoN-coNtrol side (rH uNits)
5009591
5009815
DRIP PAN, staiNless steel witHout draiN 1001976
FEET, RUBBER, 2" (51mm) for couNter toP uNits oNly (Not available oN Models built for us or caNada) ce oNly 5001614
GREASE COLLECTION UNIT Not available oN stacked uNits 5012800
LEGS asseMbly, 6" (152mm)
asseMbly, flaNged feet, 6" (152mm)
(required for stackiNg uNits)
5001414
5001761
MULTI-PURPOSE WIRE BASKET (.50 diaMeter PiN) BS-26019
SPITS aNgled sPit, staiNless steel (7 staNdard witH uNit)
PierciNg sPit, staiNless steel
turkey sPit, staiNless steel
aNgled sPit, tefloN coated
SI-25934
SI-25729
5011681
5001335
STACKING ASSEMBLY (factory iNstalled)
AR-7E OVER AR-7E (rigHt-HaNd) (208-240v, 1PH)
(208-240v, 3PH)
(380-415v)
5009981
5009982
5009983
AR-7E OVER AR-7E (left-HaNd) (208-240v, 1PH)
(208-240v, 3PH)
(380-415v)
5010355
5010356
5010357
AR-7E OVER AR-7H (208-240v, 1PH)
(208-240v, 3PH)
(380-415v)
5008787
5008948
5008922
AR-7E OVER ASC-4E
5013873
STANDS (H x W x D) ar-7e w/ sHelf, 35-15/16" x 39-3/16" x 27-1/2" (912mm x 995mm x 700mm)
ar-7e over 750-s, 36" x 39-3/16" x 27-9/16" (914mm x 995mm x 700mm)
FR-26550
5002058
NON-STICK COATED ACCESSORY - COMMERCIAL GRADE
coMMercial grade, iNcludes disks, driP tray aNd 7 aNgled sPits
5001302
OPTIONS & ACCESSORIES
