COMPONENTS
Ve ct or F ® Se ries ▪ S ervice Man ual ▪ MN -4 6 895 ▪ R ev 1 ▪ 7/ 20
33
12VAC Transformer
The transformer provides a voltage signal to the control board. The signal allows
the control board to determine the incoming line voltage.
▪ Primary: 1700 Ohms
▪ Secondary: 6 Ohms
VMC-PHD-001927
VV
240 VAC
