IMPORTANT: Read this instruction manual before you start up your high pressure washer for
the first time.
This machine is a hot water high pressure washer producing a water jet under high pressure and of a high
temperature which is why severe injuries and scalding can occur if the safety precautions are not observed.
Therefore a complete understanding of the contents of this instruction manual is required in order to prevent
injuries to yourself, objects and persons near-by, and the machine itself.
Contents GB
1.0 Survey of models
1.1 Model tag
1.2 Technical data
2.0 Instructions for use
Safety precautions and warnings
2.1 Starting-up
2.2 Operation
2.3 General
3.0 Operating instructions
3.1 Connections
1. High pressure hose
2. Water connection
3. Mains power connection
4. Fuel filling
5. Spray handle - accessories
6. Detergents - dosing unit
7. Anti-incrustation „ALTO No Scale“
3.2 Starting-up procedure
3.3 Operation
3.4 Temperature control
3.5 Spray lance, pressure regulation
3.6 End of operation
1. Dismounting of high pressure hose
2. Automatic stop
3. Stop in the event of faults
3.7 Transport directions
3.8 Storage
4.0 Fields of application and working methods
4.1 Fields of application
4.2 Working pressure
4.3 Detergents
4.4 Dosing of detergents
4.5 Working methods
5.0 Functional description
5.1 General description
5.2 High pressure pump, water system
5.3 Electric motor
5.4 Burner system - control system
5.5 Burner override mode
6.0 Maintenance
6.1 General
6.2 Descaling of coil
6.3 Cleaning of high pressure nozzle
7.0 Trouble shooting chart
Designations GB
(see drawing on the cover)
1. Spray lance
2. Spray handle
3. Electric cable
4. Water connection (water inlet filter)
5. Connection for high pressure hose
6. Hot water high pressure hose
7. Pressure gauge
8. Castor wheel with brake
9. Driving wheel
10. Winder for hose/cable
11. Fuel filter
12. Fuel filling
13. Dosing unit for detergents
14. Suction hose for detergents
15. Placing of container for detergents
16. Start/stop buttons
17. Temperature display
18. Temperature control
19. Filling of „ALTO No Scale“*
20. Indicator for „ALTO No Scale“*
21. Indicator for lack of fuel
22. Service display (digital)
23. Model tag
* anti-incrustant
United Kingdom: Health and Safety at work, Act 1974, Guidance note p.m. 29
This act imposes certain obligations with regard to safety on both operators and suppliers of machines used in the course of work.
ALTO’s policy has always been to ensure, so far as is reasonably practicable, that all ALTO products are safe and without risk to health when
properly used.
Although the proper use will vary from machine to machine there is a constant factor which cannot be overemphasized, namely the need for
a good standard of personal and industrial operation and installation.
ALTO always endeavours to provide customers with adequate information on the products they are using, by the issue of descriptive literature which
is constantly being reviewed and updated.
We would also like to remind you of the importance of avoiding misuse and the need to disseminate all relevant information to individual
employees.
If you have any doubts or problems relating to the correct installation, application, storage or handling of any of the products please do not
hesitate to contact your local ALTO distributor.
Details on earth leakage circuit breakers and monitoring devices are available on request.
ALTO Cleaning Systems Limited
Gilwilly Industrial Estate, Penrith,
Cumbria - 01768-868995
