-. POWER ON/OFF Switch
This switch is used to turn the main power ON and OFF.
-. PHANTOM ON/OFF Switch
This switch will apply +48 Volt Phantom Power only to the 2 XLR microphone inputs. Never connect microphones
when the phantom power is on already.
4.25 REAR PANEL Description
This connector is used to connect the supplied AC Adapter.
