Alto Typhoon User Manual

ON
OFF
EQ
HIGH
+15-15
0dB
HIGH
freq
KHz
16
1.6
4
MID-H
EQ
+15-15
0dB
MID-H
freq
KHz
8.8
3.2
MID-L
+15-15
0dB
MID-L
freq
Hz
160
640
1.6K
LOW
+15-15
0dB
LOW
freq
Hz
40040
160
We provided a very versatile EQ circuit with four sweep filters to satisfy professional users demand. Thanks to the
wide overlap section of the 4 filters, this EQ allows to shape in a very efficient way the sound of all the sound sources
the sound engineers has to manage.
HIGH gain
It's a shelving filter giving the user
a continuous adjustment of boost
and cut from +15dB to -15dB.
MID-H gain
It's a peak/dip filter giving the user
a continuous adjustment of boost
and cut from +15dB to -15dB.
MID-L gain
It's a peak/dip filter giving the user
a continuous adjustment of boost
and cut from +15dB to -15dB.
LOW gain
It's a shelving filter giving the user
a continuous adjustment of boost
and cut from +15dB to -15dB.
EQ LED
This useful LED will allow the sound
engineer to immediately understand
if the channel has been equalised
or not.
HIGH freq
It's the control to set the centre frequency of the
HIGH control. It can be adjusted in 1,6-16kHz
range. It affects the frequency area from the upper
fundamental frequencies up to the higher harmo-
nic frequencies, allowing the skilled user to add
brightness to sound sources as well as reduce
unwanted hiss and high frequency noises.
MID-H freq
It's the control to set the centre frequency of the
MID-H control. It can be adjusted in 0.8-8kHz
range. It affects the frequency area from the upper
fundamental frequencies up to the higher harmonic
frequencies, allowing the skilled user to add or
to subtract brightness to sound sources to avoid
masking frequencies effects.
MID-L freq
It's the control to set the centre frequency of the
MID-L control. It can be adjusted in 0.16-1.6kHz
range. It affects the frequency area of most of
fundamental tone frequencies up to lower harmo-
nic frequencies, allowing the skilled user to add/
subtract impact and/or presence to sound sources
giving them a particular sound character.
LOW freq
It's the control to set the centre frequency of the
LOW control. It can be adjusted in 40-400Hz
range. It affects the frequency area from the lower
fundamental frequencies, allowing the skilled user
to add "boominess" to sound sources as well as
to reduce unwanted hum and rumble noises.
EQ switch
This switch allows the user to use the EQ. Section
in signal path. Of course it can be used too to
make A/B comparisons between equalized signal
and not equalized signal to control the . It can be
used too to apply equalization at a certain point
of the show, excluding it when it's not necessary.
12
[ Typhoon Mono Input Channels ]
