48
LIVE RECORDING - 4F
X & 4 stage monitors/headphones
Aux sends settings:
Aux is post fader, and its signal is addressed to fx unit, whom return is connected to stereo Aux Return 1
Aux is post fader, and its signal is addressed to fx unit, whom return is connected to stereo Aux Return 2
Aux is post fader, and its signal is addressed to fx unit, whom return is connected to stereo Aux Return 3
Aux is post fader, and its signal is addressed to fx unit, whom return is connected to stereo Aux Return 4
Aux are pre-fader, their signals are addressed to LTO HPA 4 Headphone amplifier (Aux sends A-D)
Aux return channels :
- to be used for FX unit 1 return
if you're recording your mix you have to disconnect the TAPE RETURN jacks, otherwise you risk a tape feedback
to be used for FX unit 2 return
- to be used for FX unit 3 return
- to be used for FX unit 4 return
1-8 to 8 recorder inputs
1
2
3
4
5->8
AUX RETURN 1
Warning -
AUX RETURN 2 -
AUX RETURN 3
AUX RETURN 4
Groups assigns
