Amada MA-660A - Connector Specifications

MA-660A
8. Connector Specifications
8-1
8. Connector Specifications
1: RD + / SD +
2: RD – / SD –
3: NC
4: NC
5: NC
6: +24
V DC IN supplied from the
connected welding power supply
7: 0
V
8: Shield
9: NC
10: NC
CAUTION
Use the cable purchased from us.
！
1
2
3
45
6
7
8
910
